How to setup Android Navigation Component with Drawer

How to setup Android Navigation Component with Drawer .
It’s been a wile since Android team launched the new Navigation style in Android . For me , it looks amazingly cool and I thought I should…

It’s been a wile since Android team launched the new Navigation style in Android. For me , it looks amazingly cool and I thought I should share it with you.

Let’s start :

First of all , let’s start with setting up the navigation dependencies :

implementation "androidx.navigation:navigation-fragment-ktx:$rootProject.navigationVersion"
implementation "androidx.navigation:navigation-ui-ktx:$rootProject.navigationVersion"

where navigationVersion is stored in the build.gradle project module:

ext {
navigationVersion = "2.0.0"
...
}

On with the show :
In your res menu , define a new directory named navigation.

After that, create a nav_graph:

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools" android:id="@+id/treasure_nav"
app:startDestination="@id/fragment1">
    <fragment android:id="@+id/fragment1" android:name="com.stavro_xhardha.pockettreasure.Fragment1"
android:label="fragment_fragment1" tools:layout="@layout/fragment_fragment1">
<action android:id="@+id/action_fragment1_to_fragment2" app:destination="@id/fragment2"/>
</fragment>
<fragment android:id="@+id/fragment2" android:name="com.stavro_xhardha.pockettreasure.Fragment2"
android:label="fragment_fragment2" tools:layout="@layout/fragment_fragment2"/>
</navigation>

which basically is the equivalent of this:

Just two fragments connected to each other. What a destination is, is basically the view where I (or the user) needs to be. Since I will be needing to launch something when the app starts, I will define my fragment1 as start destination (never use names like that).

Setting up the main_activity view:

<?xml version="1.0" encoding="utf-8"?>
<androidx.drawerlayout.widget.DrawerLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/drawer_layout"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:fitsSystemWindows="true"
tools:context=".MainActivity"
tools:openDrawer="start">
    <LinearLayout
android:layout_width="match_parent"
android:layout_height="match_parent"
android:orientation="vertical">
        <androidx.appcompat.widget.Toolbar
android:id="@+id/toolbar"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:background="@color/colorPrimary"
android:theme="@style/ThemeOverlay.MaterialComponents.Dark.ActionBar"/>
        <fragment
android:name="androidx.navigation.fragment.NavHostFragment"
android:id="@+id/nav_host_fragment"
android:layout_width="match_parent"
android:layout_height="match_parent"
app:defaultNavHost="true"
app:navGraph="@navigation/treasure_nav"/>
</LinearLayout>

    <com.google.android.material.navigation.NavigationView
android:id="@+id/nav_view"
app:menu="@menu/activity_main_drawer"
android:layout_width="wrap_content"
android:layout_height="match_parent"
android:layout_gravity="start"
android:fitsSystemWindows="true"/>
</androidx.drawerlayout.widget.DrawerLayout>

Of course , we need these things to setup :

  • The drawer_layout, responsible for holding my menu.
  • The toolbar, responsible for holding my top left icon of the drawer.
  • The nav_host_fragment which will hold any view that I will load from the Navigation logic.
  • The nav_view responsible for my navigation.

Am I done ? Time to setup the logics:

class MainActivity : AppCompatActivity(),
AppBarConfiguration.OnNavigateUpListener {
    private lateinit var appBarConfiguration: AppBarConfiguration;
    override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
setContentView(R.layout.activity_main)
        val toolbar = findViewById<Toolbar>(R.id.toolbar)
setSupportActionBar(toolbar) //set the toolbar
        val host: NavHostFragment = supportFragmentManager
.findFragmentById(R.id.nav_host_fragment) as NavHostFragment? ?: return
val navController = host.navController
        appBarConfiguration = AppBarConfiguration(navController.graph) //configure nav controller

        setupNavigation(navController) //setup navigation
        setupActionBar(navController, appBarConfiguration) // setup action bar
        //hear for event changes
navController.addOnDestinationChangedListener { _, destination, _ ->
val dest: String = try {
resources.getResourceName(destination.id)
} catch (e: Resources.NotFoundException) {
Integer.toString(destination.id)
}
            Toast.makeText(
this@MainActivity, "Navigated to $dest",
Toast.LENGTH_SHORT
).show()
Log.d("NavigationActivity", "Navigated to $dest")
}
}
    private fun setupActionBar(
navController: NavController,
appBarConfig: AppBarConfiguration
) {
setupActionBarWithNavController(navController, appBarConfig)
}
    private fun setupNavigation(navController: NavController) {
val sideNavView = findViewById<NavigationView>(R.id.nav_view)
sideNavView?.setupWithNavController(navController)
        val drawerLayout: DrawerLayout? = findViewById(R.id.drawer_layout)

//fragments load from here but how ?
appBarConfiguration = AppBarConfiguration(
setOf(R.id.fragment1, R.id.fragment2),
drawerLayout
)
}
    override fun onCreateOptionsMenu(menu: Menu): Boolean {
val retValue = super.onCreateOptionsMenu(menu)
val navigationView = findViewById<NavigationView>(R.id.nav_view)
if (navigationView == null) {
//android needs to know what menu I need
menuInflater.inflate(R.menu.activity_main_drawer, menu)
return true
}
return retValue
}
    override fun onOptionsItemSelected(item: MenuItem?): Boolean {
//I need to open the drawer onClick
when (item!!.itemId) {
android.R.id.home ->
drawer_layout.openDrawer(GravityCompat.START)
}
return item.onNavDestinationSelected(findNavController(R.id.nav_host_fragment))
|| super.onOptionsItemSelected(item)
}
    override fun onBackPressed() {
//the code is beautiful enough without comments
if (drawer_layout.isDrawerOpen(GravityCompat.START)) {
drawer_layout.closeDrawer(GravityCompat.START)
} else {
super.onBackPressed()
}
}
}

Hope you noticed my comment here

//fragments load from here but how?

Well this is what I call great.
I don’t even need to define which menu goes where with the new navigation.
But how?
Go back to the MainActivity and you will notice this line of code: resources.getResourceName(destination.id).
Satisfied enough?

Just place the same id that you added in the nav_graph , and it will work fine.

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
tools:showIn="navigation_view">
    <group android:checkableBehavior="single">
<item
android:id="@+id/fragment1" //here , check the id on the nav_graph now :)
android:icon="@drawable/ic_names_of_god"
android:title="@string/names_of_god"/>
<item
android:id="@+id/fragment2"
android:icon="@drawable/ic_quran"
android:title="@string/quran"/>
<item
android:id="@+id/nav_calendar"
android:icon="@drawable/ic_calendar"
android:title="@string/calendar_and_events"/>
        <item
android:id="@+id/nav_tasbeeh"
android:icon="@drawable/ic_tasbeeh"
android:title="@string/tasbeeh"/>
        <item
android:id="@+id/nav_gallery"
android:icon="@drawable/ic_menu_gallery"
android:title="@string/gallery"/>
        <item
android:id="@+id/nav_news"
android:icon="@drawable/ic_news"
android:title="@string/news"/>
        <item
android:id="@+id/nav_settings"
android:icon="@drawable/ic_settings_dark_grey_24dp"
android:title="@string/action_settings"/>
</group>
    <item android:title="@string/more">
<menu>
<item
android:id="@+id/nav_finish"
android:icon="@drawable/ic_exit_to_app_dark_grey_24dp"
android:title="@string/finish"/>
</menu>
</item>
</menu>

Another thing to note here is the appBarConfiguration = AppBarConfiguration( setOf(R.id.fragment1, R.id.fragment2),
 drawerLayout )
line. Setting both of my fragment1 and fragment2 like that, it means that they will remain on the backstack after navigating to one another. That’s called placing as top level destinations.

Happy Navigating.
